Container Standard 240L bin
Sweeping width 1450mm
Power Supply 48VDC 150Ah GEL battery group; Optional Lithium batteriers
Traction Motor 48VDC 2.2kw PM motor Sealed Transaxle
Vacuum Motor 48V-1.5kw brushless motor
Working Speed Forward 0-11km/h adjustable, Reverse 0-6km/h adjustable.
Working time >5h per full charge
Horse 3m ø 125 mm optional CARBON pipe
Filter 2x HEPA efficiency and washable polyester air cartridge filter
Filter surface 30 m2
Filter cleaning system onboard automatic air pulse jet dedusting system
Nebulizer onboard automatic water spray system
Noise 65dB(A) at 3 meter
Chassis Welded steel frame and galvanised chassis
Body work stylish polyester resin
Tyres 4x 16inch tubless tyres
Curb Weight 510KG without batteries 710KG with GEL battery Group
Dimensions 2450mm×980mm×1900mm without brush,
2650mmx1450mmx1900mm with 2 brushes
Min.Turning Radius** 2000mm
Max.Gradeability 25%
Max. Climbing height 150mm climbing up, and 200mm down
Braking and Parking Regenerative and Electromachenical Braking
Charger 48V20A off-board Intelligent MCU Charger
Charging time 8h 110VAC~250VAC
Lights Twin powerful working LED safety flashing light
Bin sensor Warning buzzer and led onboard when the bin is full
Fire extinguisher 2L dry powder fire extinguisher
storeage compartment 25L Lockable compartment for personal belongings
Tool kit Broom, litter picker and bucket to collect big waste
